0826-1X1T-23-F MagJack 1000BASE-T 12 Cores 1X1 Tab Up RoHS Compliant

LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

0826-1X1T-23-F MagJack 1000BASE-T 12 Cores 1X1 Tab Up RoHS Compliant

Brand Name : LINK-PP

Model Number : 0826-1X1T-23-F

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Part Status : Active

Number of Positions/Contacts : 12P8C (RJ45, Ethernet)

PoE : Non PoE

Speed : 10/100/1000 Base-T

Shield EMI Tabs : With

LED Option : Green/Green

Contact Now

0826-1X1T-23-F 1000Base-T Magjack Specifications

Parameter Specification
Number of Ports 1 x 1
Speed 1000BASE-T
Height Profile Standard
LED Yes
LED Type Green / Green (G/G)
Operating Temperature 0°C ~ +70°C
Port Configuration Tab Up
EMI Tabs Yes
Mounting Type Through-Hole Mount
RoHS Compliant Yes

Electrical Specifications @25℃

Parameter Test Condition Specification
Turns Ratio TP1 1CT : 1CT ±2%
TP2 1CT : 1CT ±2%
TP3 1CT : 1CT ±2%
TP4 1CT : 1CT ±2%
OCL (Open Circuit Inductance) @100 kHz / 100 mVRMS, 8 mA DC Bias 350 μH MIN
Insertion Loss 0.1 MHz – 1 MHz -1.1 dB MAX
1 MHz – 65 MHz -0.5 dB MAX
65 MHz – 100 MHz -0.8 dB MAX
100 MHz – 125 MHz -1.2 dB MAX
Return Loss (MIN) 0.5 MHz – 40 MHz -18 dB
40 MHz – 100 MHz -12 + 20LOG(f/80MHz) dB
CM to CM Rejection 100 kHz – 100 MHz -30 dB MIN
CM to DM Rejection 100 kHz – 100 MHz -35 dB MIN
Hi-Pot / Isolation Voltage 1500 Vrms
Compliance 100% production tested per IEEE 802.3 isolation requirements

Notes:

  1. Plastic Housing: Thermoplastic PA, black, UL 94V-0 flammability rating.
  2. Contacts: 50-micron-inch hard gold plating (or equivalent) over a 30-micron-inch minimum nickel underplate.
  3. Output Pins: Tin-coated copper wire, Ø0.018 inch, with 100 micro-inch minimum matte tin; pins are solder-dipped.
  4. Metal Shield: Nickel-plated copper alloy (all ground leads are solder-dipped).
  5. Marking: Manufacturer logo, name, part number, and date code shall be clearly marked on the part.
  6. Certifications:cULus UL Recognized – File #E196366 and E169987, and RoHS compliant
  7. Compliance: Jack cavity conforms to FCC rules and regulations.
  8. Soldering Recommendation: Suitable for wave soldering. Suggested peak wave soldering condition: 260°C max, 10 seconds max

LPJK0071AONL Cross 0826-1X1T-23-F Drawing:

0826-1X1T-23-F MagJack 1000BASE-T 12 Cores 1X1 Tab Up RoHS Compliant

0826-1X1T-23-F MagJack 1000BASE-T 12 Cores 1X1 Tab Up RoHS Compliant

Related P/N

Manufacturer Part No. Equivalent LINK-PP Part No.
0817-1A1T-11-F / JH1026A7R LPJ1026AGNL
0821-1X1T-36-F / 08211X1T36-F LPJU3401AONL
0826-1AX1-47-F LPJK0066BHNL
0826-1C4T-23-F1 LPJK0071A4NL
0826-1D1T-23-F LPJK0071AGNL
0826-1G1T-23-F LPJK4071AWNL
0826-1G1T-32-F LPJK4036AWNL
0826-1G1T-43-F LPJK0036AWNL
0826-1K1T-23-F LPJK0071AINL
0826-1L1T-57-F LPJK1014A8NL
0826-1X1T-1-F LPJK2065AONL
0826-1X1T-23-F LPJK0071AONL
0826-1X1T-43-F LPJK0036A0NL
0826-1X1T-57 LPJK0013AONL
0826-1X1T-80 LPJK1046AONL
0826-1X1T-80-F LPJK1046AONL
0826-1X1T-AC-F LPJK2065AONL
0826-1X1T-AD-F LPJK0043AONL
